Page 98 - Arlen Ness 2020 Catalog

DRIFT, BLACK
FORGED BILLET ALUMINUM BACKING PLATE
FOR: INVERTED / METHOD / CLEAR TEAR / SIDEKICK

Patent-Pending Breather Tech Hidden Hardware
Patent-pending hidden breather technology is o-ringed Specially designed breather bolts and billet cover
at the heads, passes through the back plate plates result in a hidden hardware design with
and exits inside the throttle body the most efficient breathing system available
through proprietary shooter tubes.
Now standard on all inverted intakes

Patent-Pending Oil Catch Radius Air Inlet
New integrated oil catch ensures no engine Forged into the backing plate,
breather oil ever ends up on your filter radius air inlet provides unobstructed airflow
restricting airflow. Oil catch’s bolt-on design allows for more horsepower and torque
it to be services when its time to service the air filter.

INVERTED AIR CLEANER SERIES
The Inverted air cleaner series features our next generation patent-pending SYNTHETIC AIR FILTER
hidden breather technology and an inverted intake design that maximizes airflow 4 Handmade in the U.S.A.
by pulling in air from the face of the air cleaner, as well the perimeter of the filter. 4 Does not need oil, just wash and re-use for a long lasting performance
Each kit is machined entirely from forged billet aluminum to provide the best 4 Water resistant, which in most cases eliminates the need for a rain sock
performance and style
4 Each filter features an inverted pleated top with pleated sides to maximize
airflow by pulling in from every angle
FORGED ALUMINUM BACKING PLATE 4 Synthetic material is black, with a stainless steel jacket
4 Each backing plate is CNC machined from forged aluminum
4 Features the patented Big Sucker™ hidden breather technology 4 Machined from a single piece of forged billet aluminum
FORGED BILLET ALUMINUM AIR FILTER HOUSINGS
ENGINE & EXHAUST 4 this eliminates the need for any external hoses or hardware performance by forcing air into the inverted air filter top
Each hidden breather is o-ringed at the heads, passes through the backing plate
4
and exits at the mouth of the throttle body through proprietary shooter tubes-
4
Features an inverted intake face that acts as a velocity stack to increase
Radius air inlet provides unobstructed airflow
Specially designed breather is hidden for a clean finish
4
Eliminates oil blow-by issues associated with M8 performance intakes
4
Patent-pending oil catch integrated into the backing plate, reservoir is
4
96 serviceable
