Braking System

RSD braking systems are a result of years of thought and design practice, coupled with on track testing knowledge and off track
development. Manufactured by Performance Machine, the world leader in high performance V-Twin braking systems. Race technology
inspired design puts function and form together in a lightweight performance product. Differential bore brake calipers that take flex and
heat head on for a brake caliper that resists fading, and provides a consistent lever and powerful clamping force, stopping you quicker.
Coupled with our new Radial master cylinders, they are a maximized combo.

Brake Calipers
We’ve taken the best of brake caliper technology, high quality precision machining and trademark RSD styling to create the next step up in
braking power for your V-Twin. With GP racing architecture and weight distribution, the extra rigidity maximizes your effort at the brake lever,
stopping you faster with more feel. RSD brake calipers coupled with RSD Radial master cylinders are the ultimate V-twin braking system
providing unparalleled feel and power.

• Feature differential bore pistons (1.125” & 1.375”) that apply a different • Includes brake pads, bleeder screw, 3/8”-24 banjo bolt and sealing
force at both the leading edge and the trailing edge of the brake pads washers & shim kit
for superior braking • Available in Contrast Cut, Black Ops, Machine Ops and Chrome finishes
• Dual-disc applications require separate purchase of left and right calipers
RSD BRAKE CALIPERS - Front | 2000-16 Dyna, 2000-14 Softail except FSXTS, 2000-13 XL/ XLH models, 2000-07 FLH models with 11.5” disc, 2002-05 VRod except VRSCR
LEFT - 137 X 4B RIGHT - 137 X 4B
FINISH PART # FINISH PART #
CHROME 0053-2949-CH CHROME 0053-2948-ch
CONTRAST CUT 0053-2949-BM CONTRAST CUT 0053-2948-bm
BLACK OPS 0053-2949-SMB BLACK OPS 0053-2948-SMB
MACHINE OPS 0053-2949-SMC MACHINE OPS 0053-2948-SMC
* Sportster not compatible with stock master cylinders. Requires use of 9/16” master cylinder for single disc applications and 11/16” master cylinder for dual disc applications.
* Right side calipers are only compatible with models that came stock with dual discs.
RSD BRAKE CALIPERS & brackets - Rear | 137 x 4b
2008-16 FLH, 2008-16 VRSC, BOTH MUST HAVE RSD/PM 11.8”/300MM REAR DISC 2002-07 FLH W/ 11.5” DISC, 2005 VRSCA/B 2000-01 FLH W/ 11.5” DISC
FINISH PART # FINISH PART # FINISH PART #
CHROME 1257-0081rsd-a-ch CHROME 1290-0073rsd-ch CHROME 1287-0073rsd-ch
CONTRAST CUT 1257-0081rsd-a-bm CONTRAST CUT 1290-0073rsd-bm CONTRAST CUT 1287-0073rsd-bm
BLACK OPS 1257-0081rsd-a-smb BLACK OPS 1290-0073rsd-smb BLACK OPS 1287-0073rsd-smb
MACHINE OPS 1257-0081rsd-a-SMC MACHINE OPS 1290-0073rsd-SMC MACHINE OPS 1287-0073rsd-SMC
RSD replacement brake pads | all applications *Requires use of PM Stainless Steel brake line *Requires use of PM Stainless Steel brake line
part # 0085-2007 | MSRP $89.95 part # 0085-2007 | MSRP $89.95
PART #
0051-0602ed
