ST AHLFLEX LEITUNGEN

ST AINLESS STEEL BRAKE LINES
Seats
Stahlflex Bremsleitungen
Die Lösung für den Custom-Bike-Builder. Alle möglichen Längen und Anschluss-Fittinge
lieferbar. Hochwertige Edelstahl ummantelte Teflon-Bremsleitungen, Anschlussweite 3/8”,
mit TÜV Gutachten. Für alle Leitungen werden je zwei Anschluss-Fittinge benötigt.
Cover
Mirrors
Stainless steel brake lines
The right thing for custom bike builders. A wide selection of length and fittings. Top
quality braided steel brake lines, 3/8“ wide (TÜV approval). All of these brakelines require
adapter fittings on both ends.
Side mount
Speedometer
license plates

controls
Forward
Footpegs

Stahlflex Halter VA
Electric
Lighting
Die Lösung für jedes Custombike. Mit diesen Befestigungsklammern
lassen sich alle Stahlflex-Leitungen perfekt befestigen.
ø 1“ #54-99-920
ø 32mm #54-99-930
Grips
Lever
ø 40mm #54-99-940
Switch control
ø 45mm #54-99-950
gerade #54-99-910
Stainless steel line bracket
Riser
The solution for every Custombike. By using our clamps, every
Cables
Handlebars
stainless steel braided brake line attaches to the bike beautifully.
ø 1“ #54-99-920
ø 32mm #54-99-930
ø 40mm #54-99-940
ø 45mm #54-99-950
Road
Frames
flat #54-99-910
performance
Länge/length Silber/silver Schwarz/black Länge/length Silber/silver Schwarz/black
Shocks
10cm/4” #54-99-080 #54-99-080BLK 76cm/30” #54-99-340 #54-99-340BLK
Swingarms
13cm/5” #54-99-090 #54-99-090BLK 79cm/31” #54-99-350 #54-99-350BLK
15cm/6” #54-99-100 #54-99-100BLK 81cm/32” #54-99-360 #54-99-360BLK
18cm/7” #54-99-110 #54-99-110BLK 84cm/33” #54-99-370 #54-99-370BLK
20cm/8” #54-99-120 #54-99-120BLK 86cm/34” #54-99-380 #54-99-380BLK
Fender
Monocok
23cm/9” #54-99-130 #54-99-130BLK 89cm/35” #54-99-390 #54-99-390BLK
25cm/10” #54-99-140 #54-99-140BLK 91cm/36” #54-99-400 #54-99-400BLK
28cm/11” #54-99-150 #54-99-150BLK 94cm/37” #54-99-410 #54-99-410BLK
30cm/12” #54-99-160 #54-99-160BLK 97cm/38” #54-99-420 #54-99-420BLK
33cm/13” #54-99-170 #54-99-170BLK 99cm/39” #54-99-430 #54-99-430BLK
Tanks
Chin fairing
36cm/14” #54-99-180 #54-99-180BLK 102cm/40” #54-99-440 #54-99-440BLK
38cm/15” #54-99-190 #54-99-190BLK 104cm/41” #54-99-450 #54-99-450BLK
41cm/16” #54-99-200 #54-99-200BLK 107cm/42” #54-99-460 #54-99-460BLK
43cm/17” #54-99-210 #54-99-210BLK 109cm/43” #54-99-470 #54-99-470BLK
Tuning
46cm/18” #54-99-220 #54-99-220BLK 112cm/44” #54-99-480 #54-99-480BLK
Exhaust
Air cleaner
48cm/19” #54-99-230 #54-99-230BLK 114cm/45” #54-99-490 #54-99-490BLK
51cm/20” #54-99-240 #54-99-240BLK 117cm/46” #54-99-500 #54-99-500BLK
53cm/21” #54-99-250 #54-99-250BLK 119cm/47” #54-99-510 #54-99-510BLK
56cm/22” #54-99-260 #54-99-260BLK 122cm/48” #54-99-520 #54-99-520BLK
Wheels
Brakes
58cm/23” #54-99-270 #54-99-270BLK 124cm/49” #54-99-530 #54-99-530BLK
64cm/25” #54-99-290 #54-99-290BLK 127cm/50” #54-99-540 #54-99-540BLK
66cm/26” #54-99-300 #54-99-300BLK 130cm/51” #54-99-550 #54-99-550BLK
69cm/27” #54-99-310 #54-99-310BLK 132cm/52” #54-99-560 #54-99-560BLK
71cm/28” #54-99-320 #54-99-320BLK 135cm/53” #54-99-570 #54-99-570BLK
Tools
Small parts
73cm/29” #54-99-330 #54-99-330BLK 137cm/54” #54-99-580 #54-99-580BLK
