Page 121 - Rizoma
P. 121
FLUID RESERVOIRS
NEXT
DESIGN REGISTRATION
CT127A CT127B CT127G CT127R CT127U
Volume: 27 cm - Height: 51,5 mm - Ø min 40 mm / Ø max 65 mm.
3
Fluid tanks furnished with EDPM seal, compatible with DOT 3 / DOT 4 and DOT 5.1 oil.
Suggested use: front brake master cylinder.
The kit includes 3 hose nipples: 1pc. Ø 7 mm 90 degree + 1pc. Ø 8 mm 90 degree + 1pc. Ø 8 mm straight.
To mount the fluid tanks Adaptors are required.
DESIGN REGISTRATION
CT125A CT125B CT125G CT125R CT125U
CTM125A CTM125B CTM125G CTM125R CTM125U
Volume: 17 cm - Height: 43 mm - Ø min 36 mm / Ø max 60 mm.
3
CT - Fluid tanks furnished with EDPM seal, compatible with DOT 3 / DOT 4 and DOT 5.1 oil.
CTM - Fluid tanks furnished with NBR seal, compatible with hydraulic mineral oil.
Suggested use: clutch master cylinder.
The kit includes 3 hose nipples: 1pc. Ø 7 mm 90 degree + 1pc. Ø 8 mm 90 degree + 1pc. Ø 8 mm straight.
To mount the fluid tanks Adaptors are required.
CT115A CT115B CT115G CT115R CT115U
Volume: 12 cm - Height: 42 mm - Ø min 29 mm / Ø max 48 mm.
3
Fluid tanks furnished with EDPM seal, compatible with DOT 3 / DOT 4 and DOT 5.1 oil.
Suggested use: rear brake master cylinder.
The kit includes a Ø 8 mm hose nipple.
The kit includes 3 hose nipples CT450B CT451B CT454B CT457B
120
120
